Model SSF080112 SSF080212 SSF080126-1 SSF080226-1
Photo View
Input Voltage DC 12 DC 12 DC 26 DC 26
No. of Lamps 1 2 1 2
Lamp Wattage 8W 8W 8W 8W
Input Watts (AVG) 11W 19W 11W 21W
Input Current(AVG) 0.85 1.75 0.45 0.9
Power Factor
Bench Heat Test at 23℃ Ambient Temp 45℃
Dimensions (L*W*H) 420*182*33 420*182*33 420*182*33 420*182*33
Case Type A
Lamp Type T-5
Connection Built in Built in Built in Built in
Remark  refrigerator car refrigerator car refrigerator car refrigerator car
